GTK Theming for SGUG-RSE on IRIX

[Unxmaal]

Need themes for your fancy new Netsurf 3.10 browser running on IRIX? Here's how:

• Get some icon theme
• Go to https://www.gnome-look.org/p/1012430/ and download one of the colors you prefer, like 02-Flat-Remix-Blue-Dark_20210620.tar.xz
• scp it to your SGI
• extract it to ~/.icons
• Get https://github.com/sylphenix/Great-IMD-evo
• Move the Great-IMD-evo directory to ~/.themes
• Create a file ~/.gtkrc-2.0 :

gtk-theme-name="Great-IMD-evo" gtk-icon-theme-name="Flat-Remix-Blue-Dark" gtk-font-name="Arial 9" gtk-cursor-theme-size=0 gtk-toolbar-style=GTK_TOOLBAR_BOTH gtk-toolbar-icon-size=GTK_ICON_SIZE_LARGE_TOOLBAR gtk-button-images=1 gtk-menu-images=1 gtk-enable-event-sounds=1 gtk-enable-input-feedback-sounds=1 gtk-xft-antialias=1 gtk-xft-hinting=1 gtk-xft-hintstyle="hintslight" gtk-xft-rgba="rgb"



[jenna64bit]

I should add a couple more neat tricks / "dot files" I use for RSE. First, you can use that nice theme with GTK3 as well. For example via `~/.config/gtk-3.0/settings.ini` you can change GTK3 preferences.

[Settings]
gtk-theme-name = Great-IMD-evo
gtk-icon-theme-name = Beauty
gtk-font-name="Lucida Grande 10"

gtk-cursor-theme-size=0
gtk-toolbar-style=GTK_TOOLBAR_BOTH
gtk-toolbar-icon-size=GTK_ICON_SIZE_LARGE_TOOLBAR
gtk-button-images=1
gtk-menu-images=1
gtk-enable-event-sounds=1
gtk-enable-input-feedback-sounds=1
gtk-xft-antialias=1
gtk-xft-hinting=1
gtk-xft-hintstyle="hintslight"
gtk-xft-rgba="rgb"

Another useful one is adding entries to `~/.auxchestrc`. Really you should launch these programs with the sgugshell script itself for env settings, but I set mine up before that was ready:

Toolchest*hideTitle: TRUE

Menu RSE
{
    "Dillo"        f.checkexec.sh.le "/usr/sgug/bin/dillo"
    "GVim"        f.checkexec.sh.le "/usr/sgug/bin/gvim"
    "Pidgin"    f.checkexec.sh.le "/usr/sgug/bin/pidgin"
    "Geany"        f.checkexec.sh.le "/usr/sgug/bin/geany"
    "XOSView"    f.checkexec.sh.le "/usr/sgug/bin/xosview"
    "Mrxvt"        f.checkexec.sh.le "/usr/sgug/bin/mrxvt"
    "Nedit"        f.checkexec.sh.le "/usr/sgug/bin/nedit"
    "Claws"        f.checkexec.sh.le "/usr/sgug/bin/claws-mail"
    "DevilutionX"    f.checkexec.sh.le "/usr/sgug/bin/devilutionX"
    "XMMS"        f.checkexec.sh.le "/usr/sgug/bin/xmms"
    "Robots"    f.checkexec.sh.le "/usr/sgug/bin/gnome-robots"
    "NetSurf"    f.checkexec.sh.le "/usr/sgug/bin/netsurf-gtk2"
}

Menu ToolChest
{
    no-label    f.separator
    "RSE"        f.menu RSE
}

Another fun one, I have mrxvt set up to launch directly into the SGUG shell. It also has a solarized color theme applied! This is in `~/.mrxvtrc`

Mrxvt.backspaceKey:             ^H
Mrxvt.command:            /usr/people/jenna/bin/local_sgug_shell.sh
Mrxvt.cmdAllTabs:        True


#
# ----------------------------- TAB-BAR OPTIONS ------------------------------ #
#
Mrxvt.bottomTabbar:             False
Mrxvt.autohideTabbar:           True
Mrxvt.minVisibleTabs:           8
Mrxvt.hideButtons:              True
Mrxvt.syncTabTitle:             False
Mrxvt.titleFormat:              %n. %t
Mrxvt.tabTitle:                mrxvt rse
Mrxvt.highlightTabOnBell:       True
Mrxvt.itabBackground:           #002b36
Mrxvt.tabBackground:            #002b36
Mrxvt.itabForeground:           #839496
Mrxvt.tabForeground:            #839496

#
# ---------------------- SCROLLING / SCROLLBAR OPTIONS ----------------------- #
#

Mrxvt.scrollBar:                true
Mrxvt.scrollbarRight:           true
Mrxvt.scrollbarStyle:           sgi
Mrxvt.saveLines:                50000
Mrxvt.scrollTtyOutputInhibit:   true
Mrxvt.scrollTtyKeypress:        true

# ---------------------------------- FONTS ----------------------------------- #
#

Mrxvt.xft:                      0
Mrxvt.xftSize:                  8
Mrxvt.xftAntialias:             1
Mrxvt.xftNomFont:               1
Mrxvt.xftPSize:                 7

#
# ---------------------------------- CURSOR ---------------------------------- #
#
Mrxvt.cursorBlink:              true
Mrxvt.cursorColor:              #00ff00
Mrxvt.cursorColor2:             #000000

#
# ---------------------------------- COLORS ---------------------------------- #
#

# Solarized
Mrxvt.background: #002b36
Mrxvt.foreground: #839496

## black dark/light
Mrxvt.color0: #073642
Mrxvt.color8: #002b36

## red dark/light
Mrxvt.color1: #dc322f
Mrxvt.color9: #cb4b16

## green dark/light
Mrxvt.color2: #859900
Mrxvt.color10: #586e75

## yellow dark/light
Mrxvt.color3: #b58900
Mrxvt.color11: #657b83

## blue dark/light
Mrxvt.color4: #268bd2
Mrxvt.color12: #839496

## magenta dark/light
Mrxvt.color5: #d33682
Mrxvt.color13: #6c71c4

## cyan dark/light
Mrxvt.color6: #2aa198
Mrxvt.color14: #93a1a1

## white dark/light
Mrxvt.color7: #eee8d5
Mrxvt.color15: #fdf6e3


#
# ------------------------------- MISC OPTIONS ------------------------------- #
#

Mrxvt.internalBorder:           2
Mrxvt.cutChars:                 :=/~#@?%&_-.0123456789ABCDEFGHIJKLMNOPQRSTUVWXYZ0abcdefghijklmnopqrstuvwxyz
Mrxvt.pointerBlank:             True
Mrxvt.pointerBlankDelay:        10
Mrxvt.protectSecondary:         True

#
#                               CLASS SETTINGS
#

#
# ------------------------------- FULL SCREEN -------------------------------- #
#

FullScreen.bottomTabbar:        False
FullScreen.xftSize:             17
FullScreen.xftPSize:            12

FullScreen.minVisibleTabs:      15
FullScreen.smoothResize:        True
FullScreen.fullscreen:          True



[stormy]

Guy guys are the best thank you!



[stormy]

Just wanted to post these GTK themes here which might come in handy:

https://github.com/jujum4n/sgi-enhanced

-

Irixium

# IrixiumIrixium is a GTK3/4 theme based off of the SGI IRIX Desktop, meant to comlpement the QT based themes of the same names in KDE Plasma, though I'm not sure if it can be used outside of this...

www.gnome-look.org

Both look good!
